Usage
By connecting the VBus
®
Repeater to the VBus
®
interface
of a RESOL controller, a current of 200 mA in total can be
supplied to modules such as the SD3, AM1, or EM. Thus,
connecting several modules to one controller at once
is possible. The distance between the controller and the
module(s) can be up to 150 m.
Technical data
Housing: plastic
Protection class: IP20 / EN 60529
Dimensions: 95 x 70 x 25 mm
Input: 1 RESOL VBus
®
master (controller)
Outputs: 3 RESOL VBus
®
devices (modules, e.g. AM1,
EM, SD3, 200 mA in total)
Power supply:
Input voltage of mains adapter:
100 ... 240 V~ (50-60 Hz)
Input voltage of repeater:
12 V / 0,5 A 5.5 × 2.5 mm
Information about the product
Proper usage
The VBus
®
Repeater may only be used for the connection
between RESOL products equipped with a VBus
®
and a
RESOL controller in compliance with the technical data
specified in these instructions. Improper use excludes all
liability claims.
CE-Declaration of conformity
The product complies with the relevant directives
and is therefore labelled with the CE mark. The
Declaration of Conformity is available upon re-
quest, please contact RESOL.
Disposal
• Dispose of the packaging in an environmentally sound
manner.
• Dispose of old appliances in an environmentally sound
manner. Upon request we will take back your old ap-
pliances bought from us and guarantee an environmen-
tally sound disposal of the devices.
