Custom Blocks
Create a Custom Block
To name a custom block right click on box and the following screen will appear. Click on properties and the next screen will appear
Click on properties and the next screen will appear
Analogue Input 1
Analogue Input 2
Digital Input 1
Digital Input 2
Analogue Output
Digital Output
To create a Custom Block (The icon to the left shows a custom block with
2 Analog Inputs, 2 Digital Inputs, 1 Analog Output and 1 Digital Output)
From the file menu option, select file and click on new.
Select “New Custom Block” option
Create a program inside the custom block
Give it a sensible name and save your Custom block
Enter a name as you want it to appear in
your application
To Next Page
