The operating controls and their functions
Summary table
Element AS200
model
Description Function
A
all models Shipping stabilization; wing
screw with nut and washer
Protects the unit during transportation; must
without fail be removed before use.
AA
all models Socket Attachment point for the power cord.
B
Accessories
Sieve fixing cover, standard
Covers the upper analytical sieve; in
conjunction with the retainer nuts D or the
quick-action clamps G it secures the sieve
stack.
BB
all models Fuse holder Accepts two glass-tube fuses, 4 A, slow-
blow
C
Accessory
Sieve fixing cover, economy
Covers the upper analytical sieve; in
conjunction with the retainer nuts D it
secures the sieve stack.
CC
AS200 control Serial interface to PC In conjunction with the cable, Item No.
02.746.0023, connects the AS200 control
to a personal computer.
D
Accessory
standard and economy fixing
nuts
In conjunction with the B or C sieve fixing
cover, they secure the sieve stack.
DD
AS200 control Cover cap Protects the serial interface port against
dust and water; protection class IP 65.
E
Accessory
standard and economy
threaded spindles
Used together with the B or C sieve fixing
cover and the nuts D, they secure the sieve
stack.
F
Accessory Hex nuts
Locks the threaded spindles E, screwed in
place, on the sieve plate.
G
Accessory Quick-acting clamps Permits quick clamping and loosening of
the sieve stack in conjunction with the sieve
fixing cover B and the stationary rods H.
H
Accessory
comfort stationary rods
Allows for quick clamping and loosening of
the sieve stack in conjunction with the sieve
fixing cover G and the sieve fixing cover B.
I
Contained in
G
Lever, red Pressed upwards, it releases the sieve
fixing cover B.
J
all models
ON / OFF switch
Connects and disconnects the unit to the
line power supply.
K
Contained in
G
Lever, green When pressed repeatedly, it moves the
sieve fixing cover B downward, thus fixing
the sieve stack.
L
AS200 control Display: 0.20 to 3.00 mm Shows the vibration height (twice the ampli-
tude) from 0.20 to 3.00 mm.
