Rexing S3 - Device Components and Controls

Camera Overview
3
1. Power Port
2. Micro SD Card Slot
3. Reset Pin Hole
4. Menu Button, Mode
Switch Button
5. Record Button, Photo
Button, Up Button
6. Power Button, Screen
Button
9
45 6 78
7. Screen-view Switching, Audio
Button, Down Button
8. Confirm Button, Video Lock
Button, Wi-Fi Button
9. Rotating Front Camera (90°)
10. Rotating Rear/Cabin Cameras
(180° horizontal and 270° vertical)
11. Infrared Lights
M OK
POWER
R
1
2
3
11
10
