Rexnord Falk A - Appendix G Retaining Rings and Tooth Combinations; Retaining Rings for Bushing Nuts; Retaining Rings for Thrust Plate Kits; Tooth Combinations for Vibration Analysis

Rexnord Industries, LLC 3001 W. Canal St., Milwaukee, WI 53208-4200 USA378-200 (PN-2128394)
Telephone: 414-342-3131 Fax: 414-937-4359November 2010
e-mail: info@rexnord.com web: www.rexnord.comSupersedes 6-07
JR — Retaining Rings for Bushing Nuts
DRIVE SIZE Manufacturer Part Number
5107 Truarc N5000-237
5115 Truarc N5000-312
5203 Truarc N5000-334
5207 Eaton IN375
5215 Truarc N5000-462
5307 Eaton IN500
5315 Truarc N5000-575
JF & JSC — Retaining Rings for Thrust Plate Kits
DRIVE SIZE Manufacturer Part Number
5107 Truarc N5000-165
5115 Eaton IN225
5203 Eaton IN244
5207 Eaton IN281
5215 Eaton IN334
5307 Eaton IN375
5315 Eaton IN433
Tooth Combinations for Vibration Analysis
Type J05 — Tooth Combinations
DRIVE
SIZE
Exact
Ratio
Pinion
Ref. #3A3
Gear
Ref. #4A4
5107 5.077 13 66
5115 5.053 19 96
5203 5.071 14 71
5207 5.077 13 66
5215 4.923 13 64
5307 4.857 14 68
5315 4.857 14 68
Type J09 — Tooth Combinations
DRIVE
SIZE
Exact
Ratio
Input Output
Pinion
Ref. #1A3
Gear
Ref. #1A4
Pinion
Ref. #2A3
Gear
Ref. #4A4
5107 9.462 22 41 13 66
5115 9.357 27 50 19 96
5203 9.179 21 38 14 71
5207 9.492 23 43 13 66
5215 8.997 29 53 13 64
5307 9.131 25 47 14 68
5315 9.131 25 47 14 68
Type J14 — Tooth Combinations
DRIVE
SIZE
Exact
Ratio
Input Output
Pinion
Ref. #1A3
Gear
Ref. #1A4
Pinion
Ref. #2A3
Gear
Ref. #4A4
5107 14.43 19 54 13 66
5115 13.95 21 58 19 96
5203 14.45 20 57 14 71
5207 14.47 20 57 13 66
5215 13.60 21 58 13 64
5307 14.03 18 52 14 68
5315 13.91 22 63 14 68
Type J25 — Tooth Combinations
DRIVE
SIZE
Exact
Ratio
Input Output
Pinion
Ref. #1A3
Gear
Ref. #1A4
Pinion
Ref. #2A3
Gear
Ref. #4A4
5107 25.81 12 61 13 66
5115 24.87 13 64 19 96
5203 26 .94 16 85 14 71
5207 24.99 13 64 13 66
5215 24.94 15 76 13 64
5307 25.26 15 78 14 68
5315 25.26 15 78 14 68
Seal Housing Lip Seals for Type JSC
Type JSC — Seal Housing Lip Seals Accessory
DRIVE SIZE Falk Part No. Manufacturer’s Part No.
5107 2905318 Chicago Rawhide 17271
5115 0912859 National 470565
5203 2911847 Chicago Rawhide 26153
5207 0912835 Chicago Rawhide 29865
5215 2911957 Chicago Rawhide 34861
5307 0912741 Chicago Rawhide 34886
5315 0912741 Chicago Rawhide 34886
Retaining Rings for Bushing Nuts & Thrust Plates
Appendix G
•
Falk™
Quadrive
Shaft Mounted Drives Model A
(Page 36 of 44) Sizes 5107-5315
