Rexnord Falk Quadrive A - Parts List of Falk Part Numbers

Owners Manual • Falk Quadrive Shaft Mounted Drives Model A
(Page 16 of 52) Sizes 5107-5315
378-200 (PN-2128394) Rexnord
January 2019 3001 W. Canal St., Milwaukee, WI 53208-4200 USA
Supersedes 04-17 Telephone: 414-342-3131 Fax: 414-937-4359 www.rexnord.com
TABLE 11 — Parts List of Falk Part Numbers
Ref.
No
Part Description
DRIVE SIZE
5107  5115  5203 
5207 5215 5307 5315
Housing Components
13 Shaft Cover-LS 2109906 1164350 1164353 2110134 1164359 2110504 2110779
15 Seal Cover 4723094 4723095 4723096 4723097 4723098 4723099 4723109
16 Shaft Cover 1161865 1161866 1238030 2119130 1161870 1161870 1161870

16 Shaft Cover W/BKSP 1243290 1161866 1238019 2119130 1219342 1237944 1219342
17 Cover Spacer BKSP 1243292 1243296 2119132
19 Seal, 2916797 2921425 2921422 2921421 2904606 2921423 2922295
20 Seal, HS 2921419 2921416 2902929 2921417 2921420 2916797 2920669
30 Air Vent 0914088 0914088 0914088 0914088 0914088 0914088 0914088
80 Fastener Kit 4729000 4729000 4729032 4729049 4729064 4729082 4729100
100 Shim & Gasket Kit 4729429 4729430 0786836 0786837 0786838 0786839 0786840
Rotating Elements — J05
3A Shaft Ass'y-Inc 3A1-3A4 4729363 4729377 4729045 4729061 4729076 4729094 4729112
3A1 Bearing 2926357 2926361 2919339 2918700 2919359 0921354 2919215
3A2 Bearing 2926357 2919340 2919340 0921521 2919360 2916263 0921853
3A3 Pinion & Shaft-Inc 3A4 4729364 4729378 4729046 4729062 4729077 4729095 4729113
4A Shaft Ass'y-Inc 4A1-4A5 4729365 4729033 4729047 4729063 4729078 4729096 4729114
4A1 Bearing 4729014 4720891 2911822 2905191 0921778 0921727 0921366
4A2 Bearing 4729014 4720891 2911822 2905191 0921778 0921727 0921366
4A3 Hollow Shaft w 4A5 Key 4729016 4723015 4723028 4723039 4723050 4723061 4723073
4A4 Gear 1242585 1238105 1242878 1237897 1242848 1242860 1237763
5A Backstop Ass'y 0795654 0793995 0785596 0783905 0785610
Rotating Elements — J09
1A Shaft Ass'y W/O 1A4 Gear 4729366 4729380 4729037 4729053 4729068 4729086 4729104
1A Shaft Ass'y With 1A4 Gear 4729367 4729381 4729034 4729050 4729065 4729083 4729101
1A1 Bearing 2926357 2926361 2919339 2918700 2919359 0921354 2919215
1A2 Bearing 2926357 2919340 2919340 0921521 2919360 2916263 0921851
1A3 Pinion & Shaft w 1A5 Key 4729368 4729382 4729041 4729056 4729071 4729089 4729107
1A4 Gear 1242532 1242536 1242834 1242842 1242849 1242857 1242861
5A Backstop Ass'y 0795654 0793995 0785596 0783905 0785610 0785529 0757183
Rotating Elements — J14
1A Shaft Ass'y W/O 1A4 Gear 4729369 4729383 4729038 4729054 4729069 4729087 4729105
1A Shaft Ass'y With 1A4 Gear 4729370 4729384 4729035 4729051 4729066 4729084 4729102
1A1 Bearing 2926357 2926361 2919339 2918700 2919359 0921354 2919215
1A2 Bearing 2926357 2919340 2919340 0921521 2919360 2916263 0921851
1A3 Pinion & Shaft w 1A5 Key 4729371 4729385 4729042 4729057 4729072 4729090 4729108
1A4 Gear 1242533 1242537 1242833 1242843 1242850 1242858 1237856
1A5 Backstop Ass'y 0795654 0793995 0785596 0783905 0785610 0785529 0757183
Rotating Elements — J25
1A Shaft Ass'y W/O 1A4 Gear 4729372 4729386 4729039 4729055 4729070 4729088 4729106
1A Shaft Ass'y With 1A4 Gear 4729373 4729387 4729036 4729052 4729067 4729085 4729103
1A1 Bearing 2926357 2926361 2919339 2918700 2919359 0921354 2919215
1A2 Bearing 2926358 2926359 2919340 0921521 2919360 2916263 0921853
1A3 Pinion & Shaft w 1A5 Key 4729374 4729388 4729043 4729058 4729073 4729091 4729109
1A4 Gear 1242534 1238106 1238017 1242844 1242851 1242859 1237764
1A5 Backstop Ass'y 0795655 0795658 0785596 0783905 0785610 0785529 0757183
Rotating Elements — J09, J14, & J25
2A Shaft Ass'y-Inc 2A1-2A6 4729375 4729389 4729040 4729059 4729074 4729092 4729110
2A1 Bearing 2926359 2926360 2919338 2918700 0921350 0921793 0921850
2A2 Bearing 2926359 2926360 2919338 2918701 2916288 0921793 0921850
2A3 Pinion & Shaft w 2A4 Key 4729376 4729390 4729044 4729060 4729075 4729093 4729111
2A5 Spacer 1179876 1179877
2A6 Spacer 1161925 1163034 1161889 1163762 21200246
4A Shaft Ass'y-Inc 4A1-4A5 4729365 4729033 4729047 4729063 4729078 4729096 4729114
4A1 Bearing 4729014 4720891 2911822 2905191 0921778 0921727 0921366
4A2 Bearing 4729014 4720891 2911822 2905191 0921778 0921727 0921366
4A3 Hollow Shaft w 4A5 Key 4729016 4723015 4723028 4723039 4723050 4723061 4729115
4A4 Gear 1242585 1238105 1242878 1237897 1242848 1242860 1237763
Continued on next page.
