Falk Quadrive Shaft Mounted Drives Model A • Owners Manual
Sizes 5107-5315 (Page 17 of 52)
Rexnord (PN-2128394) 378-200
3001 W. Canal St., Milwaukee, WI 53208-4200 USA January 2019
Telephone: 414-342-3131 Fax: 414-937-4359 www.rexnord.com Supersedes 04-17
TABLE 11 — Parts List of Falk Part Numbers (Continued from Page 16)
Ref.
No.
Part Description
DRIVE SIZE
5107
5115
5203
5207 5215 5307 5315
Shaft Fan Assembly — All Ratios
6A Shaft Fan Ass'y Inc 6A1-6A4 . . . . . . . . . . . . 0785611 0785530 0785432
6A1 Fan . . . . . . . . . . . . 4729079 4729097 4729116
6A3 Guard . . . . . . . . . . . . 4729080 4729098 4729117
6A4 Backplate . . . . . . . . . . . . 4729081 4729099 4729118
c For sizes 5107J – 5203J, 4000J/5000J, revolving parts not necessarily interchangeable. Consult Service Parts Department.
For size 5315J05 only; use P/N 1161869.
TABLE 12 — Bearing Cross Reference Numbers
Falk
Part Number
Manufacturer’s Number
Tapered Roller Bearings
0921350 HM804843/HM804810
0921354 475/472
0921366 48393/48320
0921521 19138/19283-B
0921727 68462/68712
0921778 JM822049/JM822010
0921793 HM803149/HM803110
0921850 JHM807045/HM807010
0921851 46176/46368
0921853 46162/46368
2905191 497/492A
2911822 34478/34300
2916263 418/414
2916288 3879/3820
2918700 350A/352
2918701 339/332
2919215 HM813841A/HM813810
2919338 26112/26283-S
2919339 LM48548A/LM48510
2919340 17098/17244-B
2919359 386A/382A
2919360 3379/3320-B
2926357 30205M
2926358 30303M
2926359 30304M
2926360 30305M
2926361 30206M
4720891 29675/29620
4729014 JLM506810/JLM506849
c Other Falk suppliers of bearings that are considered equal to those
listed are: TRW, Fafnir, FAG and BCA.
Falk suppliers of Tapered Roller Bearings are: Timken, Bower, and
Tyson.
TABLE 13 — Viton Seal Cross Reference
Numbers
Falk Part Number
Manufacturer’s Number
Chicago Rawhide National
2902929 13661 . . .
2904606 42433 . . .
2916797 21091 . . .
2920669 23843 . . .
2921416 11207 470712V
2921417 15138 . . .
2921419 8704 481570V
2921420 18582 . . .
2921421 33699 . . .
2921422 29912 415995V
2921423 46155 . . .
2921425 27324 455315V
2922295 52498 . . .
c Subject to substitution of equivalent seals without notice.
