REXROTH EFC5610 User Manual

Easy Start Guide
Page 5
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
4. Parameters - overview
Parameter
Description
How to set
b0.00
Access to additional parameters
Default is 0 for Basic Parameters. Set to to enable Advanced Parameters.2
E0.08
Maximum output frequency (Hz)
Maximum frequency of the . Default is ; suitable for most applications.Inverter 50.00
E0.09
Output frequency high limit (Hz)
Maximum frequency of . Default is ; suitable for mostspeed reference (eg. keypad dial) 50.00
applications. Cannot be higher than E0.08.
E0.10
Output frequency low limit (Hz)
Default is 0.00; set to for most applications .05.00
E0.26
Acceleration time (s)
Default is rating dependent; set to for most applications.5
E0.27
Deceleration time (s)
Default is rating dependent; set to for most applications.5
C2.00
V/F curve mode
Default is (linear); set to 1 if the motor is driving a Fan or Centrifugal Pump.0
C1.05
Rated motor power (kW)
Set to match motor nameplate - eg. 0.8 (for 0.75kW)
C1.06
Rated motor voltage (V)
Set to match motor nameplate - eg. 230
C1.07
Rated motor current (A)
Set to match motor nameplate - eg. 3.34
C1.08
Rated motor frequency (Hz)
Default is 50.00. Change to 60.00 for 60Hz motor only - otherwise set at 50.00
C1.09
Rated motor speed (rpm)
Set to match motor nameplate - eg. 1380
C0.05
Carrier frequency (Hz)
Default is rating dependent and will suit most applications.
Increasing Carrier frequency may reduce motor noise.
The Inverter contains a number of settings
which can be changed to tailor it for use in a
wide range of applications. These settings are
known as parameters.
Parameters are typically referred to by code or
number (eg. C1.07 = Rated Motor Current)
with a description available in the manual.
The parameters listed in section 5 are intended
to provide a starting point to allow for basic
operation of the EFC 5610 Inverter.
The parameters contain critical information
essential to the correct operation of the
Inverter. Therefore, they should at least be
checked by the user before the Inverter is
operated for the first time.
5. Parameters to set before use
See section 6 to learn how to set a parameter value.
Set the following parameters to allow the EFC
5610 to control a motor with Run, Stop and
Speed Control from the keypad.
If any of the parameters have been changed
previously, follow the procedure in section 15
to reset the Inverter to Factory Defaults.
5.1 Parameters to check and values to set
Bosch Rexroth EFC 5610 Series Inverter
