3.4.2 Quick Start Parameters
Access & motor nameplate parameters
Code Name Setting range Default
At-
trib.
H39 Rated motor power 0.4...999.9 kW
Depends
on model
●
H40 Rated motor current 0.1...999.9 A ●
Start-up parameters
Code Name Setting range Default
At-
trib.
b00
Set the source of control commands (option
1 and 3 have frequency command source)
0...7 0 ●
b02
Set the source of frequency commands
(5 types of sources)
0...12 1 ●
b03 Highest frequency – HF 50.00...599.00 Hz 50.00 ●
b04 Base frequency – BF 20.00 Hz...HF 50.00 ●
b05 Base voltage – BV 400 V class: 240.0...480.0 V 380.0 ●
b06 V/f curve mode
OFF; H-00...H-15;
P-00...P-15
Depends
on model
●
b16 Acceleration time 0.1...6,500.0 s
b17 Deceleration time 0.1...6,500.0 s
b32 Starting frequency 0.00...60.00 Hz 0.50
b33 Starting holding time 0.0...10.0 s 0.0
b00 setting range:
0: Run/Stop control with digital operating panel
1: External via control terminals, Up/Down control
2: External via control terminals (including multi-speed), while <Stop> key is ac-
tivated
3: Logic control
4: External via control terminals (X3 is used to switch between internal/external
sources of frequency command, while Stop key is activated)
5: External computer controls Run/Stop, while <Stop> key is activated
6: External computer controls Run/Stop, while <Stop> key is deactivated
7: External via control terminals (X1, X2 and X3 are used to switch between
sources of frequency command, while <Stop> key is activated)
b02 setting range:
Bosch Rexroth AG
Parameter Settings
DOK-RCON01-FE*********-IN04-EN-P
21/31
