Error message and diagnosis
Code Name Setting range Default
At-
trib.
E45 Current error record
0...15 0 ★
E46 Last error record
E47 Last 2 error records
E48 Last 3 error records
b39 Data protection options and initialization 0...4 0 ●
0: No error record
1: O.C.-1, over current at constant speed
2: O.C.-2, over current during acceleration
3: O.C.-3, over current during deceleration
4: O.E.-1, over voltage at constant speed
5: O.E.-2, over voltage during acceleration
6: O.E.-3, over voltage during deceleration
7: O.L., motor overload
8: O.H., frequency converter overheat
9: d.r., drive protection
10: CPU-, EMI
11: IPH.L., input phase loss
12: oPH.L., output phase loss
13: E.-St., stopping by external abnormality command
14: O.T., motor overheat
15: CPUE, EMI
b39 setting range:
0: All parameters are readable and rewritable
1: All parameters are read-only except b01 and b39
2: Initialization to factory defaults at 50 Hz*
3: Initialization to factory defaults at 60 Hz
4: Clear all error records
*: Press and hold
<▲> key for 2 seconds to change b39 from 1 to 2, 3
or 4.
