6-4 Electrical Data Rexroth IndraDrive C
DOK-INDRV*-HCS02.1****-PR02-EN-P
Designation Symbol Unit HCS02.1E-
W0012
HCS02.1E-
W0028
HCS02.1E-
W0054
HCS02.1E-
W0070
DC bus power
U
N1
= 3 x AC 400 V, at Ta<40 °C;
t=60 s; T=10 min
without mains choke
with mains choke
P
DC_base_5
kW
1.5
1.5
4.7
4.2
6.2
9.1
8.3
13.3
Abb. 6-3: Data power section – DC bus power
CAUTION
Damage due to drive controller overload!
⇒
Make sure the specified performance data - peak
power and continuous power - are complied with by
correct drive dimensioning and selective fusing in the
mains connection.
