Hardware Installation and Reference Guide Installation
12 techsupport@ireyee.com
3.4 Bundling Cables
Note
Bundle the cables in a visually pleasing way.
Make sure that the twisted pair cables at the connectors have natural bends or bends of large radius.
Do not bind twisted pair cables too tightly, as this may press the twisted pair cables and affect their
service life and transmission performance.
Bundling steps:
(1) Bundle the hanging part of the twisted pair cables using cable ties and route them to the WAN port of the
device.
(2) Fasten the twisted pair cables to the cable trough of the mounting bracket.
(3) Extend the twisted pair cables under the device and route them in a straight line.
3.5 Verifying the Installation
Verify that the device is firmly and reliably secured.
Verify that the twisted pair cable matches the port type.
Verify that cables are properly bundled.
