Reyee RG-E6 - 1.5 Power Supply Technical Specifications

Hardware Installation and Reference Guide Product Introduction
5 techsupport@ireyee.com
Power Step
25%
Dimensions (W x D x
H)
242 mm × 242 mm × 64 mm (9.53 in. × 9.53 in. × 2.52 in.) (excluding antenna)
293 mm × 293 mm × 64 mm (11.54 in. ×11.54 in. × 2.52 in.) (including antenna)
Net Weight
1.3 kg (2.87 lbs.)
Service Ports
1 x 10/100/1000/2500 Base-T uplink WAN port
4 x 10/100/1000 Base-T downlink LAN port
Management Port
N/A
LED
1 x system LED, 1 x mesh LED
Power Supply
AC/DC power adapter (12 V/3 A DC)
Max. Power
Consumption
< 36 W
Bluetooth 5.0
Not supported
Environment
Operating temperature: -10°C to 45°C (14°F to 113°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Operating humidity: 5% to 95% RH (non-condensing)
Storage humidity: 5% to 95% RH (non-condensing)
Installation
Placed on a desktop or mounted on a wall with screws
Certification
FCC, IC, RoHS, cTUVus
MTBF
> 25000 H
1.5 Power Supply Technical Specifications
This router supports 12 V/3 A DC power supply, and is supplied with a 12V/3 A DC power adapter. Technical
specifications of the DC power cord connector:
Inner Diameter
Outer Diameter
Depth
2.10±0.1 mm (0.08±0.002 in.)
5.50±-0.05 mm (0.22±0.05
in.)
9.5mm (0.35 in.)
