Form CP-MAPS-D12 with FX05, P/N 209341 Rev 4, Page 25
Network Points List
MW025-FX0511-00A-MOD
NVO's Description Point NCI 's Point
NvoRoomstate *bd-26 nciSetpointT Duct DA Heating - High (dHH) adf-1
1 Discharge HTG nciTimeMin Heating Pull Up Time (PUt) adi-1
2 Room Heating nciSetpointT_1 Duct Discharge Air Cooling - Low (dcl) adf-2
3 Disch. Cooling nciOffsetT Reheat Offset (RSP) adf-3
4 Room Cooling nciSetpointT_19 Reheat DP Lockout (DP1) adf-14
nvoOccupied *bd-24 nciOffsetT_20 Space Heating Offset (HSo) adf-15
0 Off nciKeyTask_35 Unocc Reheat Enabled (rHE) bd-23
1 Occupied nciCoolSetpt Space Cooling Setpoint (SSP) adf-24
2 Warmup nciSetpointT_27 Room Discharge Air Heating Setpoint (rHP) adf-25
3 Night Htg Cycle nciSetpointT_28 Room Discharge Air Cooling Setpoint (rCP) adf-26
4 Night Clg Cycle nciSetpointT_32 OA Heating Lockout (oH1) adf-33
nvoState *bd-25 nciSetpointT_33 Duct Discharge Air Cooling - High (dCH) adf-36
0 Htg/Clg Deadband nciSetpointT_34 Duct Discharge Air Htg - Low (dHL) adf-37
1 Clg1, y1 nciSetpointT_35 OA Htg Low (oH3) adf-38
2 Clg2, y2 nciSetpointT_36 OA Htg High (oH2) adf-39
3 Clg3, y1 + y2 nciSetpointT_37 OA Clg Low (oC3) adf-40
6 Htg 1 nciSetpointT_38 OA Clg High (oC2) adf-41
9 Htg2 nciSetpointT_39 Setup Cooling (nSu) adf-42
12 Htg3 nciSetpointT_40 Setback Heating (nSb) adf-43
nvoOAtemperature Ambient Dry Bulb adf-19 nciDifferentialT_6 Space Cooling PropBand (SCP) adf-45
nvoDATemperature Discharge Air Temp adf-20 nciDifferentialT_7 Space Heating Prop Band (SHP) adf-46
nvoWHSP Working Heat Setpoint adf-28 ncisetpointT_43 rOH - Reheat Override - High Dry Bulb adf-48
nvoWCSP Working Cooling Setpoint adf-29 nciFloat_49 Enthalpy Setpoint (EN1) - Reference adf-53
nvodewpoint Outdoor Dewpoint adf-30 nciFloat_50 Enthalpy Setpoint (EN2) - differential adf-54
nvoSpaceTemp Space Temperature adf-31 nciFloat_51 Enthalpy Setpoint (EN3) - differential adf-55
nvoHumidity Outdoor Humidity % adf-32 NVI's Description Point
nvoRM_Htg_sp Room Heating Setpoint adf-34 nviunitenable.state On/Off Control bd-22
nvoRM_Clg_SP Room Cooling Setpoint adf-35 nviunitenable.value Value adf-21
nvoEnthalpy Outdoor Enthalpy adf-52 nviunitshutdown bd-35
nvoRH_Status Reheat Pump Output bd-37 nviUnitOccupied.value Occupied state adf-56
nviUnitOccupied.state Occupied state bd-38
Points List Notes: *When applied with N2open systems, the BD points are multistage and mapped
as an Msi point.
Room Discharge air heating setpoint = Supply air temperature to offset heating
losses in the space
Room Discharge Air Cooling Setpoint = Supply air temperature to offset heat
gains in the space
Duct Discharge Air Cooling Setpoint = Supply air value when there is no call for
cooling from the space (typically equals the space temperature)
Duct Discharge Air Heating Setpoint = Supply air value when there is no call for
heat from the space (typically equals the space temperature)
Note: Option CL47 (FIGURE 8, page 19) room dehumidistat is a mechanical
control. Room Rh is not available as a BAS point. For return air applications
(with return air dampers), there is no BAS output to override motorized damper
operation during unoccupied mode.
