Reznor FX05 - Page 28

Form CP-MAPS-D12 with FX05, P/N 209341 Rev 4, Page 27
WORKSHEET (cont’d) for Adjustable Parameters
(See pages 14-17 for explanations.)
Display
Parameter (BOLD FACE = Typical Adjustments;
UNDERLINED = Most Typical)
Adjustable Range
DEFAULT
Setting
Field Value
oH2 - Outdoor Reset Dry Bulb Heating - High
Setting
20 to 70°F
(corresponds to dHL, part load heating)
60°F
oH3 - Outdoor Reset Dry Bulb Heating - Low
Setting
-40 to 65°F
(corresponds to dHL, design load heat)
20°F
oC2 - Outdoor Reset Dry Bulb Cooling - High
Setting
70 to 130°F
(corresponds to dCL, design load cool)
75°F
oC3 - Outdoor Reset Dry Bulb Cooling - Low
Setting
58 to 85°F
(corresponds to dCH, part load cool)
60°F
H1 - Event Schedule 1 - Hour 0 to 23 hours 6
t1 - Event Schedule 1 - Minutes 0 to 59 minutes 0
H2 - Event Schedule 2 - Hour 0 to 23 hours 18
t2 - Event Schedule 2 - Minutes 0 to 59 minutes 0
H3 - Event Schedule 3 - Hour 0 to 23 hours 6
t3 - Event Schedule 3 - Minutes 0 to 59 minutes 0
H4 - Event Schedule 4 - Hour 0 to 23 hours 18
t4 - Event Schedule 4 - Minutes 0 to 59 minutes 0
UOt - Unoccupied Override Mode 0 to 800 minutes 240
NOTES:
