RGBlink M1 Quick Start

15
/25
2. Select the Audio input 1-4 for setting :
Audio Source Sel: Embedded or External
Audio Gain: The adjustment range is between 0~100
Audio Delay: The adjustment range is between 0~20ms
Audio Out Setting
1. Push [MENU] button, and enter to the menu items. Turn the rotary knob, select <Audio Out> option in LCD
screen, rotary the knob or touch the directly to confirm.
2. Select the Audio Output for setting :
Audio Source Sel: Select Layer A or Layer B
Audio Gain: The adjustment range is between 0~100
Monitor Select: Select PST or PGM
Mute: Select On or Off
BLEND Setting
1. Push [MENU] button, and enter to the menu items. Turn the rotary knob, select <BLEND>option in LCD
screen, rotary the knob or touch the directly to confirm.
Layer Select: Select Layer A or Layer B
Blending Mode: Including 3D Frame, Pure Color Frame, Outside, Inline 4 modes
Blending Width: The adjustment range is between 1~90
On/Off: Select On or Off
Audio Source Sel Embedded
Audio Gain 0
Audio Delay 0 ms
Audio Source Sel Layer A
Audio Gain 0
Monitor Select 0
Mute On
Layer Select Layer A
Blending Mode 3D Frame
Blending Width 0
On/off On
