Rheem A17 Series User Manual

12
4.0 INSTALLATION
Table 2A: Refrigerant Line Sizing Chart (English Units)
< 25 26-50 51-75 76-100 101-125 126-150
1/4" 5/8" n/a 25 / 0.99 50 / 0.98 31 / 0.97 3 / 0.97 NR NR
5/16" 5/8" 73 25 / 0.99 50 / 0.98 50 / 0.97 50 / 0.97 50 / 0.96 50 / 0.95
3/8" 5/8" 48 25 / 0.99 50 / 0.98 50 / 0.97 50 / 0.97 50 / 0.96 50 / 0.95
1/4" 3/4" * n/a 25 / 1.00 50 / 1.00 31 / 0.99 3 / 0.99 NR NR
5/16" 3/4" * 73 25 / 1.00 50 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 50 / 0.98
3/8" 3/4" * 48 25 / 1.00 50 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 50 / 0.98
5/16" 5/8" 20 25 / 0.99 50 / 0.97 50 / 0.95 50 / 0.93 34 / 0.91 NR
3/8" 5/8" 15 25 / 0.99 50 / 0.97 50 / 0.95 50 / 0.93 50 / 0.91 NR
5/16" 3/4" 20 25 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 34 / 0.97 18 / 0.96
3/8" 3/4" 15 25 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 50 / 0.97 50 / 0.96
1/2" 3/4" 0 25 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 50 / 0.97 50 / 0.96
3/8" 3/4" 0 25 / 0.99 50 / 0.98 50 / 0.97 50 / 0.95 50 / 0.94 50 / 0.93
1/2" 3/4" 0 25 / 0.99 50 / 0.98 50
/ 0.97 50 / 0.95 50 / 0.94 50 / 0.93
3/8" 7/8" 0 25 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 50 / 0.98 50 / 0.97
1/2" 7/8" 0 25 / 1.00 50 / 0.99 50 / 0.99 50 / 0.98 50 / 0.98 50 / 0.97
3/8" 3/4" 0 25 / 0.99 50 / 0.97 50 / 0.95 50 / 0.93 50 / 0.91 NR
1/2" 3/4" 0 25 / 0.99 50 / 0.97 50 / 0.95 50 / 0.93 50 / 0.91 NR
3/8" 7/8" 0 25 / 1.00 50 / 0.99 50 / 0.98 50 / 0.98 50 / 0.97 39 / 0.96
1/2" 7/8" 0 25 / 1.00 50 / 0.99 50 / 0.98 50 / 0.98 50 / 0.97 50 / 0.96
Notes:
1) Do not exceed 150  linear line length.
2) *Do not exceed 50  vercal separaon between indoor and outdoor units if the outdoor unit is above the indoor unit.
3) ** 3/4" vapor line should only be used for 2 ton systems if outdoor unit is below or at same level as indoor
unit to assure proper oil return.
4) Always use the smallest liquid line allowable to minimize refrigerant charge.
5) Applicaons shaded in light gray indicate
capacity mulpliers between 0.90 and 0.96 which are not
recommended, but are allowed.
6) Applicaons shaded in dark gray are not recommended due to excessive liquid or sucon pressure drop.
Equivalent Length (Feet)
17 SEER 2-Stage Air-Condioners
5 Ton
Unit Size
Allowable
Liquid Line
Size
Allowable
Vapor Line
Size
2.0 Ton
** SEE
NOTE 3
3 Ton
4 Ton
Outdoor Unit ABOVE or BELOW Indoor Unit
Maximum Vercal Rise (Outdo
or Unit Below Indoor Unit) * / Capacity Mulplier
Use Long Line
Guidelines for
Linear Line
Lengths
Greater
Than Shown
Below
