SECTION I: USER
21
I SECTION I: USER
I.1 DESCRIPTION OF THE MACHINE
UTNC-EV is a Box-t ype air ha ndling t ermin al unit , t o b e inst alled i n false
ceilings, with air flow and retur n directly i nto the room.
I.1.1 DECLARED CONDI TIONS OF USE
UTNC-EV is a fa n coil int en ded f or the treat ment of air (summer a nd
wint er air-conditi oning ) insid e buildings us ed f or d omestic or si milar
purpos es. T he unit is not d esigned for ins tallatio n in rooms us ed for
laun dry purposes (IEC EN 60335- 2-40 Sta ndard).
The units comply with the following Directives:
- Machiner y Directi ve 20 06/ 42/ EC (MD);
- Lo w Voltag e Directi ve 20 06/95 /EC (LVD);
- Electromagnetic Compatibility Directi ve 2004/108/EC (EMC);
DANGER !
The mach ine is designed for indoor installation
only, for use in domestic or similar environments.
DANGER !
Do not introduce objects through the air intake or
delivery gr ill es.
IMPORTANT !
The unit will function corre ctl y onl y if the
instructions for use ar e scrupulously followed, if
the spec ified cle aran ces ar e comp lied with during
installation and if the functioning restrictions
indicated in t his m anual are strictl y adh ered to.
IMPORTANT
If cle aran ce di stanc es are not maint ain ed at
inst all ation, it could cau se m aintenan ce difficu lties
and reduction in performance.
I.1.2 MACHINE IDENTIFICATION
The units have a s erial n umber plate af fixed to the insid e, which is
visible by re movi ng the air filter.
I.1.3 STRUCTURAL FEA TURES
• The self-s upporting struct ure is made of gal va nised sh eet s te el
complete wit h a de vice t hat raises the conde nsa te fr om the tra y to t he
drain level tray, a buffer ceiling with manually adjustable flow fins, return
grid and rege nerable filt er.
• Finned coil h eat e xc hang er.
• 3-spee d f an UTNC-EV.
• Brushless fan UTNC-I.
I.1.3.1 Versions
• UTNC-EV 2-pipe f an coil
• UTNC-EV/V2-V3 2-pipe fa n coil with inst alled val ve 2/3 way.
• UTNC-EV B4 4-pipe fan coil
• UTNC-EV/V2-V3B4 4-pip e f an c oil wit h inst alled val ves 2/ 3 way.
• UTNC-EV REL 2-pipe fan coil + el ectric resista nce
• UTNC-I 2-pipe fan c oil
• UTNC-I/V2-V3 2-pi pe f an coil with ins talle d val ve 2/ 3 wa y.
• UTNC-I B4 4-pipe f an coil
• UTNC-I/V2-V3B4 4- pipe fan coil with i nstalle d valves 2/3 wa y.
• UTNC-I REL 2-pipe f an c oil + electric resist anc e
I.1.4 FUNCTIONING LIMITS
IMPORTANT !
RHOSS S.p. A. shall not be h eld li able for damag e to
persons or propert y caused b y a connection that
does not comply with the indicated functioning
limits.
W ater Circuit
• Wat er side maximum pressure : 1 40 0 kPa (1 42 mwc)
• Minimum te mperat ure of t he input wat er: + 4°C
• Maxi mum t emperat ure of t he i nput wa ter: + 80°C
Env ironment air
• Minimum temperat ure: 5°C
(1)
• Maxi mum temperat ure: 32°C
Note: (1) If the room temperature is thought to drop
belo w 0°C, it i s recommend ed to empt y the water
s yste m so as to pr ev ent possibl e bre ak age du e to
frost ( see "W ater Connections" paragraph).
Electric po wer supply unit
• Sing le-phas e nomi nal voltag e 23 0V ~ 5 0Hz
I.1.5 INFORMATION REGARDING IMPROPER USE
IMPORTANT !
The mach ine has been designed and constructed
solely and exclusively to function as an air handling
terminal unit; an y other use is strictly PROHIBITED.
Inst alling t he ma chine in an explos iv e env ironment
is prohibited.
I.1.6 INFORMATION ABOU T RESIDUAL RISKS
THAT CANNO T BE ELIMINATED
IMPORTANT !
Pay the utmost attention to the symbols and
inst ruct ions lo cat ed on t he appli ance .
If a ny risks r emain in spite of th e pr ovisions ad opt ed, or if t here are an y
pot ential or hidde n risks , t hes e are indica te d b y adhesi ve labels
attac he d t o th e mac hine in c omplianc e with st andard ISO 38 64 .
I.2 ACCESSORIES AND SPARE PARTS
IMPORTANT !
Onl y us e origin al spare parts and a cc es sorie s.
RHOSS S.p.a. shall not be held liab le for damage
caus ed b y t a mpering or work carr ied out b y
unauthorised personnel or malfunctions cau sed b y
the use of non-original spare part s or accessories.
IMPORTANT !
In the case of a water supply with a particularly high
content of hard water sa lts, it is adv isabl e to fit a
water softener.
KV2 - KV3 ( supplied sepa ratel y) – 2/3- way elec troval ve for 2-pipe
systems complete with an insul ation covering (the accessory does not
come with the auxiliar y condensate drain tray).
