Installing Options
56
3
E Tighten the two screws to secure
the 1284 interface board.
Note
❒ Use the supplied adaptor to
make the connection with the
computer.
❒ After finishing installation, you
can check the 1284 interface
board is properly installed:
Print the configuration page
from the “List/Test Print”
menu. If it is installed properly,
you will see “Parallel Interface”
for “Controller Option”.
❒ If the 1284 interface board is not
installed properly, reinstall it
from step
A
. If you cannot in-
stall it properly even after at-
tempting reinstallation, contact
your sales or service representa-
tive.
Reference
For printing the configuration
page, see p.30 “Test Printing”.
AET103S
GaiaP1GB_Setup-F4_FM_forPaper.book Page 56 Friday, June 3, 2005 7:50 AM
