5. Front cover
Open to access the inside of the machine.
6. Paper tray
Load paper here.
7. Paper tray unit (Tray 2 and Tray 3)
Load paper here.
8. Main power switch
To operate the machine, the main power switch must be on. If it is off, turn the switch on.
9. Ventilation holes
Prevent overheating.
10. Internal tray guide
Open out and raise the end fence to support large paper.
Front and right view
CMR002
1
2
3
4
5
6
1. Exposure glass
Place originals face down here.
2. Right cover
Open this cover to remove jammed paper fed from the paper tray.
3. Bypass tray
Use to copy or print on OHP transparencies and label paper (adhesive labels).
4. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
5. Extender
Pull this extender out when loading paper in the bypass tray.
2. Getting Started
26
