Ricoh Aficio MP 301SPF - Guide to Components (Mainly North America)

Rear and left view
CMR016
1
1. Ventilation holes
Prevent overheating.
Guide to Components
(mainly North America)
• Do not obstruct the ventilation holes by placing objects near them or leaning things against them. If
the machine overheats, a fault might occur.
Front and left view
CMR001
1
2
3
4
5
6
7
8
9
10
2. Getting Started
30
