Ricoh Aficio MP 301SPF - Guide to Components (Mainly Asia)

6. Lower right cover
Open this cover when a paper jam occurs.
Rear and left view
CMR016
1
1. Ventilation holes
Prevent overheating.
Guide to Components (mainly Asia)
• Do not obstruct the ventilation holes by placing objects near them or leaning things against them. If
the machine overheats, a fault might occur.
Guide to Names and Functions of Components
27
