6. Align the front of the printer with the front of the paper feed unit, and slowly lower it.
Place it so that it is held firmly in place by the vertical pins.
BEK102S
Return the handle you pulled out from the printer to its original position.
7. Pull out tray 2 of the printer slowly until it stops, lift the front of the tray slightly, and then
pull out the tray completely.
BEK103S
Place the tray on a flat surface.
8. Attach a screw in the hole on the left side of the tray opening to secure the printer to the
paper feed unit.
Tighten the screw firmly using a coin.
BEK104S
