• Before using the board, you must configure settings from the printer control panel. For details, see
"Wireless LAN Configuration".
• p.64 "Wireless LAN Configuration"
Installing the IEEE 1284 Interface Board
• Before beginning work, ground yourself by touching something metal to discharge any static
electricity. Static electricity can damage the board.
• Do not subject the board to physical shocks.
• For connection to the IEEE 1284 interface board, use a half pitch 36-pin interface cable.
1. Check the contents of the package.
1. IEEE 1284 Interface Board
2. Turn the printer off and unplug the power cord.
Installing the Interface Units
43
