Wireless LAN Configuration
Configure the following wireless LAN settings according to the network environment using the control panel.
• Ethernet and Wireless LAN cannot be used at the same time.
• To use wireless LAN, set as follows using the control panel: press the [Menu] key, select [Host
Interface], [Network], [LAN Type], and then select [Wireless LAN]. In addition, you must set the IP
address, subnet mask, gateway address, DHCP, Frame Type (NW), and active protocol as explained
in "Ethernet Configuration".
• The following table shows the control panel settings and their defaults. These items appear in the [Host
Interface] menu.
Setting Name Default
Communication Mode Infrastructure Mode
Ad-hoc Channel
• When using the IEEE 802.11a/g Interface
Board:
36
• When using the IEEE 802.11g Interface
Board:
11
Communication Speed Auto
SSID Setting blank
Security Method None
1. Press the [Menu] key.
To Next Page
