Connecting to the USB port of the Gigabit Ethernet board
1. Connect the square-shaped connector of the USB cable to the USB port of the Gigabit
Ethernet board.
BEK021S
2. Connect the opposite end's flat connector to the desired device such as your computer's USB
interface, or a USB hub.
• "Installing the Printer Driver Using USB", Software Guide
• p.37 "Installing the Gigabit Ethernet Board"
USB Cable Connection
53
3
