Ricoh Aficio SP C231N

Paper Transfer
Transfer Unit
1. Open the front cover.
2. Release the locks [A].
3. Transfer unit [B]
Transfer Roller
1. Transfer Unit ( p.48)
2. Release the two hooks [A] at both sides of the transfer unit.
4. Replacement and Adjustment
48
4
