Ricoh Aficio SP C231N

Paper Exit
Paper Exit Roller
1. Operation panel ( p.24)
2. Remove the bushing [A] ( x 1)
3. Move the bushing [B] to the left side ( x 1).
4. Paper exit roller [C]
5. Remove the four exit guides [D], gear [E] ( x 1) and bushing [F].
Paper Exit
61
4
