Ricoh Aficio SP C231N

Temperature/Humidity Sensor
1. Operation panel ( p.24)
2. Rear cover ( p.23)
3. Right cover ( p.25)
4. Temperature/Humidity sensor [A] ( x 1, x 1)
Duplex Motor (M036 only)
1. Operation panel ( p.24)
2. Rear cover ( p.23)
3. Left cover ( p.25)
4. Disconnect the fusing connector [A]
Electrical Components
73
4
