Ricoh Aficio SP4100N - Attaching Hard Disk Drive Type 2650

Attaching Hard Disk Drive Type 2650
• Do not touch the inside of the controller board compartment. Doing so may cause a machine
malfunction or a burn.
• Before touching the hard disk drive, touch something metal to discharge any static electricity. Static
electricity can damage the hard disk drive.
• Do not subject the hard disk drive to physical shocks.
• Before using the new hard disk drive, be sure to make the settings in the printer driver.
1. Check the package contains the following:
Hard Disk Drive
ZKDX220J
2. Turn off the power of the printer, and then unplug the power cable.
3. Remove the two screws and the cover of the hard disk drive mounting bracket.
AUB215S
The removed screws and cover are not used when installing the hard disk drive.
