Ricoh AP610N - Aficio B/W Laser Printer - Print Area

Paper and Other Media
12
1
Print Area
The following shows the print area
for this printer. Be sure to set the print
margins correctly by the application.
❖ Paper
A Print area
B Feed direction
C Approx. 4.2 mm (0.18 inches)
D Approx. 4.2 mm (0.18 inches)
Note
❒ The print area may vary de-
pending on the paper size,
printer language and printer
driver settings.
❖ Envelope
A Print area
B Feed direction
C Approx. 4.2 mm (0.18 inches)
D Approx. 4.2 mm (0.18 inches)
Note
❒ The print area may vary de-
pending on the paper size,
printer language and printer
driver settings.
