Ricoh Caplio R1 - LCD Monitor Display

12
Names of parts
Camera
Front View
1. Shutter Release Button (P.25)
2. AF Window
3. Viewfinder
4. Lens Cover
5. Microphone (P.81)
6. Flash (P.33)
7. Power Switch (P.21)
8. Lens (P.25)
About the Mode Selector
You can select one of three modes with the mode selector.
Movie Mode Allows you to shoot movies.
Still Image Mode Allows you to shoot still images.
Voice Memo Mode Allows you to record sounds.
