Installing or removing a memory card
31
Installing and removing options
6 Make sure each latch fits over the notch on the end of the card.
Removal
1 Remove the system board access cover. (See Accessing the printer system board.)
Warning: Printer memory cards are easily damaged by static electricity. Touch something metal such as the
printer frame before you touch a memory card.
2 Push the latches away from the card on both ends of the memory card connector.
The memory card moves out of the connector as the latches open.
3 Pull the memory card out of the connector.
Avoid touching the connection points along the edge of the card.
4 Place the card into the original packaging.
If you do not have the original packaging, wrap the card in paper, and store it in a box.
5 Close both latches.
Memory connector
Memory card
