Ricoh L5160 - Symbols for Power Switch

CIP Training L5160/L5130
Throughput
1. Cleaning cartridge
A maintenance cartridge that is made up of a wiper and flushing pad. Use this
cartridge when performing head cleaning. To replace the cleaning cartridge, see
"Replacing a Cleaning Cartridge".
2. Head height adjustment knob
When the machine cannot be operated due to a media misfeed etc., raise the
print heads by turning the knob, and then move the carriage out.
3. Carriage
Discharges ink onto the media, and is equipped with print heads and a media
sensor. It is possible to adjust the height of the print heads to match the thickness
of the media. To adjust the height of the print heads, see page 147 "Head
Height".
4. Capping station
Prevents nozzles from drying by capping the print heads. To clean caps, see
"Cleaning the Caps", Requests for Daily Care and Maintenance.
5. Flushing cartridge
Use when performing head cleaning or auto maintenance. To replace the
flushing cartridges, see page 242 "Replacing a Flushing Cartridge".
6. Media guide
Set media in accordance to its width. Set the media so that both edges pass under
the media guides.
7. Platen
This is the media feeding surface (printing range). Clean this area if the back of
the printed media becomes dirty. See "Cleaning the Platen", Requests for Daily
Care and Maintenance.
8. Vacuum hole
Sucks media and prevents it from rising.
9. Feed roller
Feeds media.
10. Pinch roller
Holds down set media from above.
Symbols for Power Switch
Symbols for power switch that are used for this machine are as follows:
• : POWER ON
• : STANDBY
Heater
There are 4 heaters built into this machine to maintain print quality. The location of
each heater and its function is as follows.
