Guide to Functions of the Attention Light
• Do not push or pull the attention light when it is installed to the machine. Doing so
may result in damage or malfunction of the attention light or the machine.
CUV121
The attention light notifies the user
by light when there is a media jam
or no media is left. The colors of
the lamp and their meanings are as
follows:
Lamp Status
The bottom lamp lights blue. Printing
The bottom lamp flashes blue. Data in
The top lamp lights red. Error occurred
(Example)
• When the service call message appears
• Media jam
• Out of media
• Out of ink
Read the message on the display panel, and then
take appropriate action.
Lamp Status
The top lamp flashes yellow. Warning
(Example)
• Ink has nearly run out.
• Waste ink bottle is nearly full.
Read the message on the display panel, and then
take appropriate action.
