Ricoh MP 4054 Series User Guide

5. Print
This chapter describes frequently used printer functions and operations. For information not included in
this chapter, see Print available on our website.
Quick Install
You can install the printer drivers easily from the CD-ROM provided with this machine.
Using Quick Install, the PCL 6 printer driver is installed under network environment, and the Standard
TCP/IP port will be set.
• Manage Printers permission is required to install the drivers. Log on as an Administrators group
member.
1. Click [Quick Install] on the installer screen.
2. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next >].
3. Click [Next >].
4. Select the machine model you want to use in the [Select Printer] dialog box.
5. Click [Install].
6. Configure the user code, default printer, and shared printer as necessary.
7. Click [Continue].
The installation starts.
8. Click [Finish].
When you are prompted to restart your computer, restart it by following the instructions that
appear.
9. Click [Exit] in the first window of the installer, and then take out the CD-ROM.
123

Ricoh MP 4054 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Hard Disk Drive	320 GB
Copy Resolution	600 x 600 dpi
Print Speed	40 ppm
Paper Capacity	1, 200 sheets standard, up to 4, 700 sheets maximum
Maximum Paper Size	11" x 17"
Memory	2 GB
Connectivity	Ethernet, USB
Functions	Print, Copy, Scan
Scan Resolution	600 dpi
Fax Transmission Speed	33.6 kbps
Copy Speed	40 ppm (B&W)
Operating System Compatibility	Windows, Mac, Linux
