Ricoh P C301W - Guide to the Machine; Guide to Components; Exterior:front View

1. Guide to the Machine
This chapter describes preparations for using the machine and its operating instructions.
Guide to Components
This section introduces the names of the various parts on the front and rear side of the machine and
outlines their functions.
Exterior:Front View
ECB102
12
11 10
9
8
7
6
5
4321
No. Name Description
1 Control Panel Contains keys for machine control and indicators that
show the machine status.
2 Top Cover Open this cover to replace the print cartridge.
3 Standard Tray Extension Use this to support sheets that come out curled after they
are printed.
Flip open the extension by pushing down on the end
that is toward the rear of the machine.
