3. Push the metal plate down until it clicks.
ECC077
4. Pinch the extender, and then pull out the extender until it clicks.
ECC110
After extension, check that the arrows on the extender and tray are aligned.
ECC111
5. Follow Steps 3 to 7 in "Loading Paper into Tray1 and 2".
To reinsert the extender, you might have to push it with moderate force.
2. Paper Specifications and Adding Paper
30
