Introduction
Input/Output Connections
Monitor loop
through only
support in
Computer-In/
YPbPr.
1. Computer-In/YPbPr Connector
(PC Analog Signal/Component Video Input/HDTV/YPbPr)
2. HDMI2 Input Connector
3. HDMI1 Input Connector
4. Service
5. Power Socket
6. Monitor-Out Connector
7. PC Control (9-pin DIN Type)
8. Video Input Connector
9. Audio Input 2 (right) Connector
10. Audio Input 2 (left) Connector
11. Audio Output Connector (3.5mm mini jack)
12. Audio Input 1 Connector (3.5mm mini jack)
13. Microphone Input Connector
14. Kensington
TM
Lock Port
The interface
is subject to
model’s
specications.
5
1 2
4
7
11
3
8
9
6
10
12
14
13
