Ricoh Pro 8210 - Replacing Rollers in Wide LCT 5;6

(3) Pick-up roller and snap ring
1
2
3
CZC157
8. Slide the bracket back to its original position, and then secure it with the screw.
CZC024
9. Push the paper feed unit into the machine, and then secure it with the 2 screws.
4
5
CZC023
2. Replacing the Paper Feed Rollers
42
