Clearing Paper Misfeeds.
Throughput
CIP Training Pro C5200 series
• When you close the upper right cover of the machine while the bypass tray is open, push
the mark on the upper right cover.
• When you open the upper left cover of the wide large capacity tray to remove misfed
paper, open the upper left cover completely until it stops.
• When opening the drawer, make sure to completely pull it out toward you. If the cover
of the fusing unit is caught with the main unit, hold the handle at the center of the
drawer and pull the drawer out forcibly so that the whole fusing unit protrudes from the
front cover.
Locating jammed paper
If a misfeed occurs, remove the jammed paper by following the procedures indicated in the
animation that appears on the screen and the sticker or sheet inside the front cover.
A misfeed has occurred in the place corresponding to the letter displayed on the control panel.
To Next Page
