Ricoh Pro C7100 Technical Bulletin

Technical Bulletin PAGE: 1/8
Model: BR-C1/BR-P1
Date: 28-Sep-15
No.: RD777003
Supplementary Explanation on the Adjustments to Prevent No-feed and
Double-feed Jams in the Vacuum Feed LCIT
The vacuum feed LCIT can feed a wide range of media, but is also susceptible to paper
curl by the nature of its mechanism of blowing air to separate the sheets. This bulletin
provides explanations on the adjustments to prevent double-feed and no-feed jams,
especially caused by paper curl. The main jam codes are as follows:
Jam type
Jam location
Jam code
No-feed
Upper Tray of 1st LCIT
J430
Lower Tray of 1st LCIT
J431
Upper Tray of 2nd LCIT
J445
Lower Tray of 2nd LCIT
J446
Jam type
Jam location
Jam code
Double-feed
Upper Tray of 1st LCIT
J470
Lower Tray of 1st LCIT
J471
Upper Tray of 2nd LCIT
J485
Lower Tray of 2nd LCIT
J486
Subject: Adjustments in Vacuum Feed LCIT to prevent no-feed
and double-feed jams for BR-C1/P1
Prepared by: J. Ohno
From: 1st PP Tech Service Sec., PP Tech Service Dept.,
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety
Other ( )
