Ricoh Pro C7100 Technical Bulletin

Technical Bulletin PAGE: 1/13
Reissued: 17-Jan-17
Model: Vacuum Feed LCIT RT5100
Date: 20-Oct-16
No.: RD777010b
RTB Reissue
The items in bold italics were changed or added.
The following parts were modified to prevent the tray lift wire from breaking.
The modified parts have been applied to mass production since July 2016.
Follow the procedures described in this bulletin when installing or replacing with the
modified parts for units manufactured before July 2016.
Modified parts
Items
New P/N
Description
Qty required
for 1 Tray
Page # in
this RTB
Pulley Cover
D7772784
COVER:WIRE:PULLEY
2
5
Collar
D7772769
COLLAR:BASE
2
8
Stud
D7777769
STUD:PAPER TRAY
2
9
Ball Bearing Ass'y
(Rear)
D7772745
ROLLER:TRAY BOTTOM
PLATE:REAR RIGHT:SUB-ASS'Y
1
9
Ball Bearing Ass'y
(Front)
D7772746
ROLLER:TRAY BOTTOM
PLATE:FRONT RIGHT:SUB-ASS'Y
1
9
Sheet (Front)
D7772655
SHEET:HOOK:WIRE:FRONT
2
10
Sheet (Rear)
D7772657
SHEET:HOOK:WIRE:REAR
2
11
Subject: Modified parts to prevent paper tray lift wire breakage /
replacement procedure
Prepared by: Hiroaki H Matsui
From: 1st PP Tech Service Sec., PP Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety
Other ( )
Tier 2
Tier 0.5
