Technical Bulletin PAGE: 5/5
2. Remove the two screws to pull out the paper feed unit [A] and slowly turn the paper
feed belt [B] with your hands. This will connect the spring pin with the coupling.
3. Push the paper feed belt unit back in and confirm that there is no gap between the
frames. Repeat Step 2 until you confirm that there is no gap.
4. Fasten the paper feed belt unit with the screws.
