Placing Originals in the Auto Document Feeder
Be sure not to block the sensor or load the original untidily. Doing so may cause the machine to detect
the size of the original incorrectly or display a paper misfeed message. Also, be sure not to place
originals or other objects on the top cover. Doing so may cause a malfunction.
1. Sensors
2. Original guide
1. Adjust the original guide to the original size.
2. Place the aligned originals squarely face up in the ADF.
Do not stack originals beyond the limit mark.
The first page should be on the top.
1. Limit mark
• For information on using the ADF, see "Specifying the Settings for Originals", Basic Operations.
• Straighten curls in the originals before placing them in the ADF.
• To prevent multiple sheets from being fed at once, fan the original before placing it in the ADF.
• When originals are loaded in the ADF, the bottom plate rises automatically.
6. Paper Specifications and Adding Paper
168
