Ricoh SP 311DN - By-Pass Feed Roller Friction Pad

Paper Feed
M154/M155/M174/M175/A0A7/M287/M0BB 4-18 SM
9. Slide the by-pass feed roller shaft [A] to the left side, and remove it.
10. Remove the metal cover [B] from the by-pass feed roller [C].
4.5.5 BY-PASS FEED ROLLER FRICTION PAD
1. By-pass feed roller (page 4-17 "By-pass Feed Roller")
2. By-pass feed roller friction pad [A] (2 hooks, spring x 1)
