Paper Feed
M0C3/M0C4/M0C5/M0C6/M0C7 4-58 SM
27. Remove the registration roller (drive) [A] ( x 2, bushing x 2).
4.7.12 REGISTRATION SENSOR
1. Remove the registration unit (Registration Roller).
2. Turn the registration unit over.
3. Remove the registration sensor [A] (
x 1, 3 hooks).
