Ricoh SP 3710SF Service Manual

Maintenance Mode (for Four-line LCD Models)
SM 5-9 M0C3/M0C4/M0C5/M0C6/M0C7
System
Maintenance
Menu Description
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Flatbed Main Reg. Adjusts the Flatbed Scan main-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Flatbed Sub Reg. Adjusts the Flatbed Scan sub-scan magnification.
[-0.9 to 0.9 / 0 (Default)/ 0.1 %/step]
Factory Default
Menu Description
Factory
Default
Return Does not execute anything. Returns to an upper level.
Execute
Resets all the settings to factory default.
Clears/ resets the contents of the controller memory (all data
programmed by the user, log data application counters) to factory default.
After executing, initial setup menu starts after power-on.
CTL Maintenance
Menu Description
PDL Mode
ON = "PDL Settings" is shown in [Print List/Report] menu (Default)
OFF = "PDL Settings" is hidden
FW Update
Mode
If updating firmware on a machine in which LDAP authentication is set, execute this
mode.
[Execute/ Return]
After pressing “Execute”, the display shows “Please Restart Machine….” Turn the
machine's main power off, and then on. Then the machine activates in a special
boot loader mode. After that, update the firmware via USB cable.
Auto IP
ON = Automatically set an IP address when an IP address cannot be acquired
(Default)
OFF = Continually try to obtain an IP address by DHCP
Disable
USB Port
Sets whether the USB port function is valid or invalid
[Off (Default)/On]
Paas
Validity
Setting
When used to set Paas (Only for CHN)
[Inactive (Default)/ Active]

Ricoh SP 3710SF Specifications

General

Included cartridge capacity (black)	7000 pages
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	120 W
Power consumption (PowerSave)	0.87 W
Power consumption (average operating)	1025 W
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Envelopes, Legal
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	50 sheets
Maximum input capacity	300 sheets
Auto document feeder (ADF)	Yes
Auto document feeder (ADF) input capacity	35 sheets
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	MH, MMR (Fax coding method), MR
Fax resolution (black)	300 x 200 DPI
Scan to	E-mail, FTP, TWAIN, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Scan speed (black)	4.5 ppm
Scan speed (color)	13 ppm
Optical scanning resolution	19200 x 19200 DPI
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Maximum duty cycle	35000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Print technology	Inkjet
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Control type	Touch
Product color	Gray
Display diagonal	4.3 \
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.10 Yosemite
Linux operating systems supported	Ubuntu 16.04, Ubuntu 16.10, openSUSE 13.1, openSUSE 13.2
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP
USB 2.0 ports quantity	2
Internal memory	256 MB
Processor frequency	400 MHz
Card reader integrated	No

Weight and Dimensions

Depth	392 mm
Width	405 mm
Height	420 mm
Weight	18000 g
