Laser Exposure
SM 7-21 M0C3/M0C4/M0C5/M0C6/M0C7
Descriptions
7.6 LASER EXPOSURE
7.6.1 OVERVIEW
No. Item No. Item
1. Synchronization detector 7. Polygon mirror motor
2. Laser synchronization detector lens 8. Laser unit thermistor
3. LD driver board 9. Drum
4. Aperture 10. FTL lens
5. Cylindrical lens 11. Shield glass
6. Shield glass 12. Mirror
