Guide to Names and Functions of Components
Guide to Components
• Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
Exterior: Front view
321
4
7
8
6
5
1011 912
14
15
13
DBQ006
1. Front cover
Open to access the inside of the printer and remove jammed paper.
Open here to replace the print cartridge and the drum unit.
2. Tray Extension
Pull this fence to prevent paper from falling off.
